CH-280HA Horizontal Metal Saw Cutting Machine

Name: CH280HA Horizontal Metal Saw Cutting Machine
Brand: CHENLONG
Price: 5 USD

Quality CH-280HA Horizontal Metal Saw Cutting Machine for sale

Place of Origin : Zhejiang, China

Brand Name : CHENLONG

Supply Ability : 500 Set/Sets per Month

Packaging Details : plywood case + angle iron pallet.

MOQ : 1 Set/Sets

Price : $5,950.00 - $13,720.00 / Set

Delivery Time : 40days

Power (kW) : 2.2

Weight (KG) : 1376

Key Selling Points : Energy saving

Warranty : 1 YEAR

After-sales Service Provided : Free spare parts, Online support, Free spare parts

Applicable Industries : Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Farms, Construction works , Energy & Mining, Metal Processing Factory

Brand : CHENLONG

Automatic grade : Automatic

Color : Bule and white

Usage : Mass production

Voltage : 380v/3ph/50hz

Type : Pivot Horizontal

Blade : 1 pc

Clamping : Hydraulic

Saw Frame Feeding : Hydraulic

Port : Ningbo.

Contact Now

CHENLONG CH-280HA Horizontal Metal Saw Cutting Machine

CH-280HA Horizontal Metal Saw Cutting Machine

Product parameters

Model Name	New	CH-280HA (Double Column Fully Auto)
	Original
Max.cutting	Round	280mm	Bundle	200×150mm
capacity	Quadrate	280×280mm, 350×280mm	cutting
Saw blade	Speed	20 to 80 m/min(inverter)
	Size	27×0.9×3620mm
	Guides	Carbide and bearing blade guides
	Cleaning	Power wire brush & flood coolant
	Tension	Hydraulic
Motor output	Blade	2.2kw
	Hydraulic	0.75kw
	Coolant	0.06kw
Multiple feed		400mm × 9 times
Work Vise		Hydraulic
Gross Weight		1376kg
Packing Size(L×W×H)		2310×2210×1440mm
Standard Equipment:
1. Power blade cleaning brush.
2. Working light.
3. Fast approaching device.
4. Roller rack 2M long
5. One piece of bi-metal saw blade.
6. One set of tools with tool box
7. NC control
8. Automatic chip converyor
9. Bunddle cutting device
10. Hydraulic blade tension

CH-280HA Horizontal Metal Saw Cutting Machine
